Falcata XP 12

Falcata Xtremely Precise

Ideally-suited for transflection measurements in process applications. The high-performance measuring head enables extremely precise and reliable measurement results. Available in diameters 6 mm and 12 mm.

Suitable for transparent or slightly turbid media



  • Reaction monitoring in chemical synthesis
  • Control of process chromatography
  • Determination of color numbers
  • Versatile due to exchangeable path length inserts





Falcata XP 12

Model series Falcata XP 12
Measuring principle TRANSFLEXION
Outer Diameter 12 mm | 1/2 inch
Diameter Probe Barrel 12 mm
Optical Path / Focal Length Set (1, 2, 5, 10 and 20 mm)
Optical Tolerance Quartz ±0.04 mm, Sapphire ±0.04 mm
Optical Material Quartz Glass
Probe Body Material Stainless Steel 1.4435/1.4404 (316L)
Sealing Technology Kalrez 6375
Spectral Range NIR
Wavelenghts for: UV/Vis: 230 - 1100 nm; NIR: 400 - 2300 nm
Optical Connection 2 m glass fiber PE coated, 2x F-SMA and PMA housing
Connection Glass fiber core 600 µm and NA 0.22, housing: with sockets NW23 /with ext. glass fibers NW17
Fiber Optic Technology Standard fiber optic
Process Connection Without Flange
Probe Barrel Not suitable for Swagelok
Maximum Pressure 40 bar (Class 300, overpressure at RT, 31 bar at 200 °C, 27 bar at 300 °C, 25 bar at 400 °C)
Temperature Restrictions T max: optical connector 150 °C (without ext. fiber), Copex PMA 130 °C (85 °C for ATEX)
Maximum Immersion Depth
Length of Probe Barrel Without flange: immersion depth + 10 mm, with flange: immersion depth + 50 mm
Additional Functions None
ATEX Suitability
Temperature 5 °C to 180 °C
Pressure -1 bar to 40 bar
Delivery Immersion Probe, Optical Path Length Tip/Tips, Manual, Certificate of the pressure test, Protocol of transmission test, Transport packaging
Expected delivery time on request
Article number PF2FQSZNEASL___N
Price per unit on request
Quantity 1

More informationLess information


Falcata XP 6

Model series Falcata XP 6
Measuring principle TRANSFLEXION
Outer Diameter 6 mm | 1/4 inch
Diameter Probe Barrel 6 mm
Optical Path / Focal Length Set (1, 2, 5, 10 and 20 mm)
Optical Tolerance Quartz ±0.04 mm, Sapphire ±0.04 mm
Optical Material Quartz Glass
Probe Body Material Stainless Steel 1.4435/1.4404 (316L)
Sealing Technology Kalrez 6375
Spectral Range NIR
Wavelenghts for UV/Vis: 230 - 1100 nm; NIR: 400 - 2300 nm
Optical Connection 2 m glass fiber PE coated, 2x F-SMA and PMA housing
Connection Glass fiber core 600 µm and NA 0.22, housing: with sockets NW23 /with ext. glass fibers NW17
Fiber Optic Technology Standard fiber optic
Process Connection Without Flange
Probe Barrel Not suitable for Swagelok
Maximum Pressure 40 bar (Class 300, overpressure at RT, 31 bar at 200 °C, 27 bar at 300 °C, 25 bar at 400 °C)
Temperature Restrictions T max: optical connector 150 °C (without ext. fiber), Copex PMA 130 °C (85 °C for ATEX)
Maximum Immersion Depth 240 mm
Minimum immersion depth 25 mm
Length of Probe Barrel Without flange: immersion depth +10 mm, with flange: immersion depth + 50 mm
Additional Functions None
ATEX Suitability
Temperature 5 °C to 180 °C
Pressure -1 bar to 40 bar
Delivery Immersion Probe, Optical Path Length Tip/Tips, Manual, Certificate of the pressure test, Protocol of transmission test, Transport packaging
Expected delivery time on request
Article number PF1FQSZNEASL240N
Price per unit on request
Quantity 1

More informationLess information

Products of the brand:

Falcata = Transflexion

HD = Heavy duty

XP = Xtremely precise
